SUPPORT-COMPRESSOR 1569688 - Caterpillar

Illustration 1 g00577995
Elevator Speed Control - The elevator speed control (lever) is located at the right of the operator's seat. The elevator speed control lever is a variable speed control for the elevator. The speed of the elevator can be matched to loading conditions. Reverse (1) - Push the lever away from the operator in order to unload the machine. The lever will remain in the detent position. The elevator will continue to operate until the lever is moved out of the detent position.Hold (2) - In the Hold position, the elevator will not move. The elevator will remain in the Hold position until the lever is moved to an other position.Low Speed Forward (3) - Pull the lever partially toward the operator and release the lever in order to load the machine. The lever will remain in the detent position. The elevator will continue to operate until the lever is moved out of the detent position.High Speed Forward (4) - Pull the lever all the way toward the operator and release the lever in order to load the machine. The lever will remain in the detent position. The elevator will continue to operate until the lever is moved out of the detent position.
Illustration 2 g00577999
Elevator Direction Control - The elevator direction control (lever) is located at the right of the operator's seat. The lever controls the direction of rotation of the elevator. Forward (1) - Push the lever forward in order to operate the elevator in a forward direction.Reverse (2) - Pull the lever backward in order to operate the elevator in a reverse direction.
